Fiber Bragg Grating (FBG) Temperature Sensor, T04

Name: Fiber Bragg Grating (FBG) Temperature Sensor, T04
Brand: T&S Communications Co., Ltd.

Identifier: 160008

-20°C~120°C | Accuracy:±1°C | Resolution: 0.1°C | 1510nm~1590nm

Features

High accuracy
High stability and reliability
Good adaptation to harsh environment
Good EMI performance
Convenient for networking and multipoint measurement.

Specification Drawings Request Quote

Product Description of Fiber Bragg Grating (FBG) Temperature Sensor, T04

T04 FBG temperature sensor makes use of the inherent temperature sensitivity of fiber Bragg grating to detect temperature. It has excellent waterproof performance and can be embedded or installed on the surface of subject to be measured. It is suitable for temperature monitoring and fire alarm in oil storage tank, tunnel, concrete, dam and other fields.

Specifications

Item	Unit	Specification
Temperature Resolution	°C	0.1
Temperature Accuracy	°C	±1
Measuring Range	°C	-20~120
Central Wavelength	nm	1510~1590
Connector Type	-	FC/APC or customized
Dimension	mm	Ø8×100
Pigtail Type	-	Ø3mm armored cable
Pigtail Length	-	customized

Applications

Multipoint temperature sensing
