T&S Communication TSPA-85192-xxxC is a Pluggable SFP for 10 Gigabit Ethernet, compliant with the SFF-8431. This transceiver is a high-performance module for short-range data communication and interconnect applications. The length up to 150 m using OM2 MMF or 300 m using OM3 MMF.
Electrical interface compliant to SFF-8431
850nm VCSEL laser and PIN photo-detector
Maximum link length of 150m on OM2 MMF and 300m on OM3 MMF
Hot Pluggable
Built-in digital diagnostic functions
Operating case temperature 0°C to 70°C
RoHS compliant
10G Ethernet, Data Centers
Infiniband transmission
Parameter | Symbol | Min | Max | Unit |
Storage Temperature | TS | -20 | 85 | °C |
Relative Humidity | RH | 0 | 85 | % |
Case Operating Temperature | TCase | 0 | 70 | °C |
Supply Voltage | VCC | -0.5 | 3.6 | V |
Parameter | Symbol | Min | Typical | Max | Unit |
Case Operating Temperature | TCase | 0 | - | 70 | °C |
Supply Voltage | VCC | 3.13 | 3.3 | 3.47 | V |
Supply Current | Icc | 0 | - | 150 | mA |
Data Rate | DR | - | 10.3125 | - | Gbit/s |
Parameter | Symbol | Min | Typical | Max | Unit |
Input differential impedance | Zin | 90 | 100 | 110 | Ohm |
Differential Data Input Swing | Vin | 200 | - | 1600 | mVp-p |
Transmit Enable Voltage | VEN | - | - | 0.8 | V |
Transmit Disable Voltage | VD | 2.0 | - | - | V |
Average launch power | PAVG | -6.5 | -1 | - | dBm |
Extinction Ratio | ER | 3.0 | - | - | dB |
Parameter | Symbol | Min | Typical | Max | Unit |
Differential Data Output Swing | Vout | 370 | - | 1600 | mVp-p |
Bit Error Rate | BER | - | - | 10-12 | - |
Receiver Overload | Pinmax | 2.5 | - | - | dBm |
Output Differential Impedance | Zout | 90 | 100 | 110 | Ohm |
LOS Fault | VOH | 2.4 | - | - | V |
LOS Normal | VOL | - | - | 0.4 | V |
| PIN | Symbol | Name/Description |
| 1 | VeeT | Transmitter Signal Ground |
| 2 | TX_FAULT | Transmitter Fault (LVTTL-O) – Not used. Grounded inside the module |
| 3 | TX_DISABLE | Transmitter Disable (LVTTL-I) – High or open disables the transmitter |
| 4 | SDA | Two Wire Serial Interface Data Line (LVCMOS – I/O) |
| (same as MOD-DEF2 in INF-8074) | ||
| 5 | SCL | Two Wire Serial Interface Clock Line (LVCMOS – I/O) |
| (same as MOD-DEF1 in INF-8074) | ||
| 6 | MOD_ABS | Module Absent (Output), connected to VeeT or VeeR in the module |
| 7 | RS0 | Rate Select 0 - Not used, Presents high input impedance. |
| 8 | RX_LOS | Receiver Loss of Signal (LVTTL-O) |
| 9 | RS1 | Rate Select 1 - Not used, Presents high input impedance. |
| 10 | VeeR | Receiver Signal Ground |
| 11 | VeeR | Receiver Signal Ground |
| 12 | RD- | Receiver Data Out Inverted (CML-O) |
| 13 | RD+ | Receiver Data Out (CML-O) |
| 14 | VeeR | Receiver Signal Ground |
| 15 | VccR | Receiver Power + 3.3 V |
| 16 | VccT | Transmitter Power + 3.3 V |
| 17 | VeeT | Transmitter Signal Ground |
| 18 | TD+ | Transmitter Data In (CML-I) |
| 19 | TD- | Transmitter Data In Inverted (CML-I) |
| 20 | VeeT | Transmitter Signal Ground |
