Grade B Patch Cord Connector

Grade B Patch Cord

Grade B Patch Cord Connector

T&S grade B patch cord connector is the patchcord with the random mating performance of Grade B as IEC-61753-1 defined, more than 97% of maximum 0.25dB random mated with each other and the average is less than 0.12dB. Simplex, duplex grade B patchcord is well fabricated and all grade B connectors (including LC, MU, SC, FC, etc.) are compliant to IEC-61754, end face geometry is superior to IEC-61755. As an experienced fiber patch cord manufacturer, T&S provides high-quality grade B patch cord connector for years.

Grade B Patch Cord Basic Info

With the advances in fiber optic technology and transmission systems, reliable cabling systems are becoming even more important. Active optical equipment, which is often worth hundreds of thousands of dollars, is all connected to the network via the humble fiber optic patch cord or patch lead. The risk of network downtime due to unreliable cabling is one that should be avoided. Therefore, these types of networks, along with many other Data Center and high-speed Commercial networks require reliable patch cord connector infrastructure in order to maximize performance and to ensure long-term reliability.


Grade B Patch Cord Connector Features

  • IEC 61753-1 random mating grade B

  • Precision zirconia ferrules for patch cord connector

  • LC, MU, SC, FC, ST, all single fiber connector

  • Usually available on single-mode connector

  • Excellent geometry and end face appearance

  • Good repeatability and interchangeability

  • Flame retardant optical fiber cable


Standard Compliance of Grade B Patch Cord

  • Connector compliant to IEC 61754

  • Optical fiber cable compliant to IEC 60793

  • ITU G.657

  • Qualified to Telcordia GR-326-Core

  • Reach, RoHS and SvHC compliant

Grade B Patch Cord Cable Specifications

Technical Specification
Fiber Optical Cable Specification

Items

Description

Connector Type

LC/MU/SC/FC/ST/Others

Polishing Type

UPC/APC 8°/APC 9°

Insertion Loss (dB)

≤0.20

Random mating loss (dB)

Max. 0.12dB mean, Max 0.25dB for 97% of samples

Return Loss (dB)

UPC ≥ 50, APC ≥ 65

Wavelength (nm)

1310/1550

Installation Temperature (°C)

-20 to 70

Storage Temperature (°C)

-40 to +85

Items

Description

Fiber Brand

Corning ClearCurve or customized

Bend Radius

10mm / 7.5mm / 5mm

Fiber Attenuation

0.35dB at 1310nm, 0.2dB at 1550nm

Fiber Count

Simplex, Duplex

Cable OD (mm)

0.9 / 2.0 /3.0, or customized

Cable Jacket

Riser, Plenum, LSZH or customized

Jacket Color

Yellow, Blue, White or customized

Strength Member

Aramid Yarn


Optical Fiber Connector Grades of Grade B Patch Cord Connector

IEC standards dictate the patch cord connector performance for each grade of fiber-optic patch cord connector based on IEC 61753-1. As defined, there are four grades for insertion loss from A (best) to D (worst). For conventional patch cord connector, mated performance is over 0.5dB, even to 1.0dB. This may cause the whole high-speed optical connection system unreliable and transmission unstable. Therefore, the grade B patch cord connector is stable with the excellent optical performance of a maximum 0.25dB while mating each other which is a guarantee for hundreds of gigabit data exchange with connections.


Grade

Average of Random Mating

97% of Random Mating

A*

Not Defined

Not Defined

B

≤0.12 dB

≤0.25 dB

C

≤0.25 dB

≤0.50 dB

D

≤0.50 dB

≤1.0 dB


Remark: Grade A is not determined yet according IEC 61753-1



Grade B Patch Cord Cable Mechanical Data


Grade B Patch Cord Cable Mechnical Data


Fiber Count

OD (mm)

Nominal

Max. Tension (N)

Max. Crushing Resistance (N/100mm)



Weight (kg/km)

Short Term

Long Term

Short Term

Long Term

Simplex 1.6

1.6±0.2

2.6

80

40

500

100

Simplex 2.0

1.9±0.2

4.5

100

60

500

100

Simplex 3.0

2.8±0.2

7.5

100

60

500

100

Duplex 1.6

3.4±0.2 x 1.6±0.2

5.3

80

40

500

100

Duplex 2.0

4.0±0.2 x 1.9±0.2

8.7

200

100

500

100

Duplex 3.0

5.8±0.3 x 2.8±0.3

14.8

200

100

500

100
